橋梁模態頻率與運營環境作用的相關性

周毅; 孫利民; 謝謨文; 喬蘭

doi:10.13374/j.issn2095-9389.2018.03.003

橋梁模態頻率與運營環境作用的相關性

doi: 10.13374/j.issn2095-9389.2018.03.003

周毅¹,
孫利民²,
謝謨文¹,
喬蘭^1, ,

1) 北京科技大學土木與資源工程學院, 北京 100083;
2) 同濟大學土木工程防災國家重點實驗室, 上海 200092

基金項目:

中國博士后科學基金資助項目(2016M600925)

中央高校基本科研業務費專項資金資助項目(FRF-TP-16-012A1)

國家自然科學基金資助項目(51608034)

詳細信息

中圖分類號: TU311.3
計量
- 文章訪問數: 677
- HTML全文瀏覽量: 301
- PDF下載量: 17
- 被引次數: 0
出版歷程
- 收稿日期: 2017-09-13

Correlation of modal frequency variation for a bridge with operational and environmental actions

1) School of Civil and Resource Engineering, University of Science and Technology Beijing, Beijing 100083, China;
2) State Key Laboratory for Disaster Reduction in Civil Engineering, Tongji University, Shanghai 200092, China

摘要

摘要: 橋梁模態頻率隨運營環境作用的變化規律是結構健康監測的研究主題之一.根據東海大橋6 a監測數據的周期變化特性,識別了運營條件下主梁豎彎、側彎、扭轉基頻變化的影響因素,采用偏相關系數和周期平均法對比了各因素的影響程度.研究發現,東海大橋的模態頻率存在1 a、1周、1 d、12.42 h等變化周期,與結構溫度、交通荷載、風荷載、海面高度等的變化周期相吻合;結構溫度和交通荷載是引起該橋頻率變化的最主要因素,它們在各周期上的相對影響大小不同;周期平均法可有效分離監測數據中的年、周、天周期成分,揭示不同運營環境作用與頻率變化的相關性.研究結果有助于加深對橋梁運營期頻率變化的理解,從而更準確地評估結構性能.
- 橋梁 /
- 模態頻率 /
- 運營環境作用 /
- 相關性 /
- 結構健康監測
Abstract: In the vibration based structural health monitoring (VBSHM) field, the modal frequency of a structure is commonly used as an indicator for the global health condition of the structure. However, field measurements have shown that the modal frequency of a bridge varies with structural anomalies and the operational and environmental actions, e. g., temperature and traffic loading. Moreover, the latter variation usually exceeds the frequency shifts induced by the small and medium structural anomalies. To highlight the anomaly-induced frequency changes, the variability of modal frequencies of bridges with the operational and environmental actions must be investigated, and then, the action-induced frequency variations need to be eliminated. According to the periodic characteristics of the six-year monitoring data of the Donghai Bridge, this research identified the main actions that affected the modal frequencies of the first vertical/lateral bending modes and torsional mode of the girder of this bridge, and further, it compared the relative contributions of actions to the variability of frequencies through the partial correlation coefficients and the proposed cyclic averaging method. The results show that the modal frequencies of the Donghai Bridge vary at cycles as 1 a, 1 week, 1 d, and 12.42 h, which coincide with the inherent predominant cycles of structural temperature, traffic loading, wind loading, and sea levels, respectively. Structural temperature and traffic loading are the most influential factors for the frequency variation, and their relative importance is different for each individual cycle. The results also show that the cyclic averaging method can effectively separate the components in periods of 1 a, 1 week, and 1 d and can disclose the inherent correlation between actions and modal frequencies. This study helps in enhancing the understanding of the frequency variability for operational bridges and may lead to a more reliable evaluation of structural performance.
- bridge /
- modal frequency /
- operational and environmental actions /
- correlation /
- structural health monitoring

HTML全文

參考文獻(15)

[1]	Fan W, Qiao P Z. Vibration-based damage identification methods:a review and comparative study. Struct Health Monit, 2011, 10(1):83
[2]	Ralbovsky M, Deix S, Flesch R. Frequency changes in frequencybased damage identification. Struct Infrastruct Eng, 2010, 6(5):611
[4]	Magalhães F, Cunha A, Caetano E. Vibration based structural health monitoring of an arch bridge:from automated OMA to damage detection. Mech Syst Signal Process, 2012, 28:212
[5]	Gentile C, Saisi A. Operational modal testing of historic structures at different levels of excitation. Constr Build Mater, 2013, 48:1273
[6]	Xu Y L, Xia Y. Structural Health Monitoring of Long-Span Suspension Bridges. Abingdon:Spon Press, 2011
[7]	Ding Y L, Li A Q. Temperature-induced variations of measured modal frequencies of steel box girder for a long-span suspension bridge. Int J Steel Struct, 2011, 11(2):145
[9]	Zhou H F, Ni Y Q, Ko J M. Eliminating temperature effect in vibration-based structural damage detection. J Eng Mech, 2011, 137(12):785
[10]	Xia Y, Chen B, Weng S, et al. Temperature effect on vibration properties of civil structures:a literature review and case studies. J Civil Struct Health Moni, 2012, 2(1):29
[11]	Mosavi A A, Seracino R, Rizkalla S. Effect of temperature on daily modal variability of a steel-concrete composite bridge. J Bridge Eng, 2012, 17(6):979
[12]	He X F. Vibration-Based Damage Identification and Health Monitoring of Civil Structures[Dissertation]. San Diego:University of California, 2008
[13]	Peeters B, De Roeck G. One-year monitoring of the Z24-Bridge:environmental effects versus damage events. Earthquake Eng Struct Dyn, 2001, 30:149
[14]	Moser P, Moaveni B. Environmental effects on the identified natural frequencies of the Dowling Hall Footbridge. Mech Syst Signal Process, 2011, 25(7):2336
[15]	Wattana K, Nishio M. Traffic volume estimation in a cable-stayed bridge using dynamic responses acquired in the structural health monitoring. Struct Control Health Monit, 2017, 24(4):e1890
[16]	Magalhaes F, Cunha A. Automated identification of the modal parameters of a cable-stayed bridge:influence of the wind conditions. Smart Struct Syst, 2016, 17(3):431
[17]	Cross E J, Koo K Y, Brownjohn J M W, et al. Long-term monitoring and data analysis of the Tamar Bridge. Mech Syst Signal Process, 2013, 35(1-2):16
