Effect of test temperature on SCC behavior of Z3CN20-09M stainless steel in high temperature water containing chloride ions
-
摘要: 研究了溫度對核電用Z3CN20-09M不銹鋼在含Cl的高溫高壓水中的應力腐蝕開裂行為的影響.材料的應力腐蝕開裂敏感性變化趨勢與試驗溫度變化趨勢并不一致.320℃時材料的應力腐蝕開裂敏感性最高,290℃時為最低,250℃時開裂敏感性介于兩者之間.250℃和320℃條件下腐蝕后試樣表面形成了內部致密、外部疏松的雙層氧化膜,而在290℃條件下腐蝕后試樣形成的是致密的單層氧化膜.大多數點蝕坑產生于鐵素體相.應力腐蝕裂紋優先在點蝕坑底部或相界面形核,并傾向于沿相界面或向鐵素體內部擴展.鐵素體/奧氏體界面對應力腐蝕裂紋的作用取決于裂紋面與相界面的取向關系.當裂紋擴展方向平行于相界面時,裂紋易沿著相界擴展;當裂紋擴展方向垂直于相界面時,相界面對裂紋擴展起阻礙作用.Abstract: The effect of test temperature on the stress corrosion cracking (SCC) behavior of Z3CN20-09M stainless steel was studied in high temperature water containing Cl-. It is shown that the changing tendency of sensitivity to SCC is not consistent with test temperature. The sensitivity to SCC achieves maximum at 320℃ and minimum at 290℃, and it is in the middle at 250℃. Bi-layer oxidation films with a compact inner layer and a loose outer layer form on the sample surface when the temperature is 250℃ and 320℃; but when the temperature is 290℃, there is only a single compact layer oxidation film. Most of corrosion pits form in ferrite. SCC cracks usually initiate preferentially at the bottom of corrosion pits or along austenite/ferrite phase boundaries, and they are inclined to propagate along the phase boundaries or within ferrite. The effect of austenite/ferrite phase boundaries on SCC cracks strongly depends on the relative orientation of SCC cracks to the phase boundaries. When the SCC crack propagates parallel to the phase boundary, it is inclined to propagate along the phase boundary; but when the SCC crack propagates perpendicularly to the phase boundary, the phase boundary hinders its propagation.
-
