Fluid-solid coupling dynamic response analysis of a simplified desulfurization tower model
-
摘要: 為研究流固耦合對脫硫塔結構簡化模型動力反應的影響,采用有限元程序(Adina)模擬脫硫塔結構簡化模型在地震作用下的流固耦合效應.首先對脫硫塔結構進行合理簡化,在不同液位下進行了脫硫塔結構的模態分析,研究了塔內液位高度對脫硫塔結構的頻率和振型的影響;其次,通過對脫硫塔結構進行地震波加載,研究了塔內液位高度、地震波輸入角度和加速度峰值對脫硫塔結構的位移和加速度的影響,并與試驗結果進行比較.結果表明,脫硫塔結構的頻率會隨著液位增高而減小,塔內液位高度、地震波加載方向及加速度峰值對脫硫塔結構加速度的影響比較大,而對其位移影響不大.Abstract: In order to study the influence of fluid-solid coupling on the dynamic response of a simplified desulfurization tower structure model,the fluid-solid coupling effects of the model under seismic waves were simulated by using the finite element program Adina.Firstly,the desulfurization tower structure was reasonably simplified,its modal analysis was done at different liquid levels,and the influences of the liquid level on its self-oscillation frequency and vibration mode were analyzed.Secondly,the effects of the liquid level,the input angle and the peak value of earthquake acceleration on the acceleration and displacement of the desulfurization tower were discussed by loading seismic waves and were compared with experimental results.The result shows that the self-oscillation frequency intensifies with the liquid level rising.The liquid level,the input angle and the peak value of earthquake acceleration all have great influence on the acceleration of the desulfurization tower,but they have little effect on the displacement of the desulfurization tower.
-
Key words:
- desulfurization /
- boilers /
- fluid-solid coupling /
- dynamic analysis /
- seismic waves /
- displacement /
- acceleration
-
