Preparation and performance of Mg-4%Ni-1%NiO hydrogen storage materials by cryomilling
-
摘要:
采用低溫球磨技術制備了Mg-4%Ni-1%NiO儲氫材料,主要研究低溫球磨時間對材料形貌結構以及儲氫性能的影響.采用掃描電子顯微鏡(SEM)和X射線衍射(XRD)分析材料的形貌和相組成,采用壓力-組成-溫度(P-C-T)設備研究材料的儲氫性能.結果表明:分別經過2、4和7 h球磨后,材料的相組成沒有發生明顯改變,只有極少量的Mg2Ni合金相生成.隨著球磨時間的延長,材料的平均粒度逐漸下降,作為催化劑的Ni、NiO相逐漸揉進基體內部.伴隨著上述變化,材料的活化性能、吸氫性能逐漸提高,球磨到7 h后材料僅需活化1次即可達到最大吸放氫速率,初始吸氫溫度降為60℃,在4.0 MPa初始氫壓和200℃下吸氫量為6.4%(質量分數),60s即可完成飽和吸氫量的80%,10min內完成飽和吸氫量的90%;材料的放氫性能則在球磨4 h后已經基本保持不變,0.1MPa下初始放氫溫度為310℃,在350℃、0.1MPa下材料可在500s內釋放飽和儲氫量的80%.
Abstract:A novel material Mg-4%Ni-1%NiO for hydrogen storage applications was fabricated by mechanical milling at cryogenic temperature(cryomilling).The effects of ball milling time on the structure morphology and the hydrogen storage performance of the newly developed materials were investigated at cryogenic temperature.The phase structure and surface morphology were analyzed by X-ray diffraction(XRD) and scanning electron microscopy(SEM).The hydrogenation and dehydrogenation characteristics were studied by a pressure-composition-temperature(P-C-T) apparatus.It is shown that the phase structure of the materials remains almost unchanged even after 2,4,and 7h of ball milling,respectively and only a small amount of Mg2Ni forms.However,a sharp depreciation in the average particle size of the alloy was observed with the ball milling time prolonging.Furthermore,there are Ni and NiO particles in the Mg matrix.In company with the changes above,the activation performance and absorption performance of the materials are gradually improved.The materials ball-milled for 7h can reach the maximal desorption rate after one activation,the onset desorption temperature is 60℃,the compounds exhibit a hydrogen storage capacity of 6.4%(mass fraction) at 200℃ under the hydrogen pressure of 4.0 MPa,and they can absorb 80% of their full hydrogen capacity in 60s and 90% in 10 min.As the ball milling time is prolonged to 4h,the performance of the materials is stable,the onset desorption temperature is 310℃ under 0.1 MPa,and the materials are able to desorb about 80% of their full hydrogen capacity in 500s at 350℃ under the hydrogen pressure of 0.1 MPa.
-
Key words:
- hydrogen storage materials /
- magnesium /
- cryomilling /
- hydrogen storage property
-
