Influencing factors on cooling uniformity of large caliber seamless steel pipes during quenching
-
摘要: 根據目前無縫鋼管常用的外表面常壓管射流與內表面軸向噴射冷卻方式,采用有限元分析軟件ANSYS對大口徑鋼管淬火過程溫度場進行數值模擬.分析了鋼管的管徑、鋼管的旋轉速度及內噴射冷卻介質-水的浸潤角對鋼管徑向冷卻均勻的影響.結果表明:在大管徑條件下,管徑對冷卻均勻影響不大;鋼管的旋轉速度不低于60 r·min-1,水的浸潤角為270°左右時,鋼管徑向冷卻均勻較好.Abstract: Based on current cooling methods commonly used to cool the outer surface by a low pressure pipe jet and the inner surface by a high pressure axial jet, numerical simulations with finite element software ANSYS were performed to study the temperature field of large-caliber seamless steel pipes during quenching. The considered factors are the diameter of steel pipes, the rotation speed of steel pipes and the wetting angle of cooling water. Numerical results reveal that pipe diameter has little influence on the cooling uniformity. The radial cooling uniformity of steel pipes is the best under the condition of the rotation speed of no less than 60 r·min-1 and the wetting angle of about 270o.
-
Key words:
- steel pipe /
- quenching /
- temperature distribution /
- numerical methods
-
