Phase-domain filtering pick-up method for roll eccentricity compensation control
-
摘要: 在深入分析機架偏心作用機制的基礎上,提出了軋機偏心補償控制信息相域濾波提取方法,它利用機架偏心軋制作用強度與軋制過程中軋輥的機械轉動相位密切相關的特點,將軋機的時域軋制數據轉換為以軋輥轉動相位為參變量的數據進行處理.在線性化相域空間中,與軋輥偏心作用相關的信號呈現出顯著的周期化特征,而其余的原時域周期信號在轉換過程中均被非周期化.在線性化相域空間中,將軋輥轉動軋制作用的往復周期作為指定的循環統計量統計周期.理論分析表明,基于統計方法能夠有效地消除噪聲的影響,同時抑制非指定線性化相域循環分量,實現機架偏心特性信息的有效獲取,其實質是線性化相域空間中的梳狀濾波器濾波.依據統計獲取的機架偏心特征信息可以為軋機偏心補償提供一定的數據參考.Abstract: A phase-domain filtering pick-up method for roll eccentricity compensation control is proposed by analyzing the mechanism of action of roll eccentricity. This method utilizes the character that the effect intensity of roll eccentricity is closely related to the rotating phase of rollers. In the method the time-domain eccentricity data are transformed to the phase domain of the roller's rotating movement first, and then processed. In the linear phase domain, the eccentricity-related signal shows distinct periodicity, and the periodicity of the other periodic signals in time-domain is weakened during this transformation. The roller's rotating period is used as the target period for cyclic statistics in the linear phase domain. Theoretic analysis indicates that the effect of noise is eliminated and some unwanted periodic signals are choked by the statistics, so the roll eccentricity characteristic information can be picked up adequately. The essential of this proposed method is a kind of comb filter in linear phase-domain. The eccentricity characteristic information can give data support for eccentricity compensation.
-
Key words:
- rolling mills /
- eccentricity /
- compensation /
- comb filters /
- signal processing
-
