Measurement of chatter marks on the backup roll of a cold temper mill
-
摘要: 針對某1700冷軋平整機支持輥表面振紋問題進行了連續跟蹤測試.在對平整機固有特性研究的基礎上,通過對支持輥各個使用時期內振動信號的分析與比較,得到了平整機的振動特征以及振動與振紋之間的相互影響關系:在支持輥使用初期,平整機系統的振動以自激振動為主,振動頻率為150Hz,在穩定軋制階段工作輥對支持輥的相對運動形成支持輥表面振紋;在支持輥使用中后期,由振紋引起的強迫振動進一步加速了振紋的形成,系統的振動為強迫振動和自激振動共存.在對振紋形成過程認識的基礎上提出了振紋抑制措施,即在軋件入口側增加抑振輥或改變軋制速度.Abstract: Continuous tracking measurements were conducted for eliminating the chatter marks of a 1700 temper mill. The character of vibration and the interaction between vibration and chatter marks were found based on the study of inherent characteristics of the temper mill and the analysis of vibration signals in different periods. The primary vibration model was self-sustained vibration and the vibration frequency was 150 Hz in initial stage, but in steady stage the relative movement between the work roll and the backup roll induced chatter marks. In middle and final period the primary vibration model was a coexistence of forced vibration and self-sustained vibration, and the forming process of chatter marks was accelerated by forced vibration resulted from chatter marks. Based on the above studies some countermeasures are derived as follows:adding a roll to control vibration in the inlet side or changing the speed of temper rolling.
-
Key words:
- temper mill /
- chatter marks /
- self-sustained vibration /
- forced vibration
-
