Application of an auto-disturbances-rejection controller in variable-frequency speed regulation systems
-
摘要: 針對矢量控制系統存在的參數魯棒性差這一難點問題,基于自抗擾控制原理,提出了將轉子時間常數的變化看作磁鏈子系統的一種內擾,轉子磁鏈幅值的變化對轉速子系統的影響作為轉速子系統的內擾,負載對轉速子系統的影響作為轉速子系統的外擾,并分別通過擴張狀態觀測器的擴張狀態予以估計和補償的感應電機變頻調速系統新型控制方案.該方案有效地解決了參數時變對矢量控制系統解耦性能的影響以及一般矢量控制系統存在的快速性與平穩性矛盾,仿真結果證明了方案的正確性與有效性.Abstract: In order to solve the poor robustness of parameters in a vector control system, a new kind of control scheme for induction-motor variable-frequency speed regulation systems was proposed based on the theory of auto-disturbances-rejection control (ADRC). In the control scheme, the change in rotor time constant was regarded as the inner disturbance of the flux subsystem, the effect of the change in rotor flux linkage amplitude and that of load as the inner and exterior disturbances of the rotate speed subsystem respectively, and the extended state of an extended state observer (ES()) was used for estimation and compensation. The control scheme can solve such problems as the effect of time-varying parameter on the decoupling performance of a vector control system and the contradiction between speediness and stability in common vector control systems. Simulated results indicated the rationality and validity of the scheme abovementioned.
-
