Removal of the Hydrogen Induced Defects Microdefects in FZ(H) Silicon and Application in Thyristors
-
摘要: 氫氣氛下區熔拉制的鼓棱無位錯硅單晶,原生晶體經化學腐蝕,觀察不到缺陷,包括微缺陷。但當塊狀熱處理后,經腐蝕常常觀察到尺度mm數量級的氫致缺陷(φ型缺陷、麻坑)和微缺陷氫沉淀。為了消除這些缺陷,原生單晶需片狀供應,片厚應小于1mm,或中照后的區熔(氫)硅單晶,片狀,940℃、0.5h退火,均能消除之。在電力電子器件的應用中,管芯等級合格率可保持在80%以上Abstract: Monocrystalline dislocation-free silicon is grown by FZ in pure hydrogen atmosphere. Defects including microdefects can not be observed in as-grown monocrystalline dislocation-free silicon afteretching. But hydrogen induced defects and microdefects in FZ(H) Si will be always observed as FZ(H) Si rod after annealing. In order to remove the hydrogen induced defects and microdefects, the as-grown FZ(H) Si rod had to cut into the wafer which thickness is less than 1mm or NTD FZ(H) Si wafer is treatmented at the 940℃/0.5h. The qualified ratio was greater than 80% in the application of msnufacturing thyristors.
-
Key words:
- silicon /
- monocrystalline /
- hydrogen /
- precipitation
-
